Round tube insert - Rounded ROPL

Round tube insert - Rounded - White


bouchon-plastique.com | Frame ROPL is round plastic inserts intended for inside protection and closing for metal & plastic round tube.

ROPL
PLASTIC INSERTS FOR ROUND TUBE WITH FLAT COVER SURFACE
Material: LDPE
Colour : Black - White - Grey - Other colour on request
Dimensions : mm

The white rounded wing cap adds a flawless finishing touch to light-coloured tubular structures. This thin convex cap is particularly popular in sectors where aesthetics and hygiene are paramount, such as office design, the medical sector and events. Its smooth surface and bright colour elegantly conceal any screws and nuts that may protrude from the ends of the tubes.

Performance of the white LDPE material

The LDPE (Low Density Polyethylene) used by Plastem guarantees a finished product that is both flexible and waterproof. Unlike other rigid plastics, it does not mark floors and is highly resistant to common cleaning products. Its slightly domed head offers a ‘convex’ design that softens the lines of your metal or plastic structures.

Installation and dimensional adaptability

The winged end cap is quick to insert and requires no special tools. The wings bend during insertion to create permanent tension against the inner wall of the tube.

Size calculation: Select your reference based on the outer diameter of your tube (available up to 88.9 mm).

Wall thickness: Compatible with tubes ranging from 0.8 mm to 3.5 mm thick.

This end cap is the ideal solution for chair legs, display structures or interior railings, offering ultimate protection against dust intrusion while enhancing the overall design.

Reference Details Sold by Price tax excl Details
ROPL10_0.8_1.5W Convex round inserts for tube OD 10 mm Wall 0,8-1,5 - White Prix/pce - Price/pce 0.1825 Details
ROPL12_0.8_1.5W Convex round inserts for tube OD 12 mm Wall 0,8-1,5 - White Prix/pce - Price/pce 0.1825 Details
ROPL13_0.8_2W Convex round inserts for tube OD 13 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.1941 Details
ROPL14_0.8_2W Convex round inserts for tube OD 14 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.1941 Details
ROPL15_0.8_2W Convex round inserts for tube OD 15 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.1941 Details
ROPL16_0.8_2W Convex round inserts for tube OD 16 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.1941 Details
ROPL18_0.25_1.5W Convex round inserts for tube OD 18 mm Wall 0,25-1,5 - White Prix/pce - Price/pce 0.2234 Details
ROPL18_0.8_2W Convex round inserts for tube OD 18 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.2121 Details
ROPL18_2.5_3.5W Convex round inserts for tube OD 18 mm Wall 2,5-3,5 - White Prix/pce - Price/pce 0.2562 Details
ROPL19_0.8_2.5W Convex round inserts for tube OD 19 mm Wall 0,8-2,5 - White Prix/pce - Price/pce 0.2282 Details
ROPL20_0.8_2.5W Convex round inserts for tube OD 20 mm Wall 0,8-2,5 - White Prix/pce - Price/pce 0.2177 Details
ROPL21_0.8_2.5W Convex round inserts for tube OD 21 mm Wall 0,8-2,5 - White Prix/pce - Price/pce 0.2282 Details
ROPL22_0.8_3W Convex round inserts for tube OD 22 mm Wall 0,8-3 - White Prix/pce - Price/pce 0.2177 Details
ROPL22_1.8_3.5W Convex round inserts for tube OD 22 mm Wall 1,8-3,5 - White Prix/pce - Price/pce 0.3135 Details
ROPL23_0.8_3W Convex round inserts for tube OD 23 mm Wall 0,8-2 - White Prix/pce - Price/pce 0.2281 Details
ROPL24_0.8_2.5W Convex round inserts for tube OD 24 mm Wall 0,8-2,5 - White Prix/pce - Price/pce 0.2177 Details
ROPL25.4_1.2_3.2W Convex round inserts for tube OD 25,4 mm Wall 1,2-3,2 - White Prix/pce - Price/pce 0.2414 Details
ROPL25_1_2.5W Convex round inserts for tube OD 25 mm Wall 1-2,5 - White Prix/pce - Price/pce 0.2414 Details
ROPL25_3_5W Convex round inserts for tube OD 25 mm Wall 3-5 - White Prix/pce - Price/pce 0.2708 Details
ROPL26_0.8_3W Convex round inserts for tube OD 26 mm Wall 0,8-3 - White Prix/pce - Price/pce 0.2346 Details
